G-98028
G-98028
2x2 center line troffer
2X2 Center Line Troffer
Dimmable
3280/4330/5390 Lumens
30/40/50 Watts
120-277 V
Couldn't load pickup availability
Information
General Specs
Product Code
G-98028
Description
F/2X2/50W/CL/WS3/5CCT
size
2X2
diffuser
Clear
number of lights
1
height
4.17"
mounting
Lay In
Packaging Information
master pack
1
Barcode
024431980281
Light Specs
temp
Selectable CCT
Color (CCT)
30,35,41,50,65K
lumens
3280/4330/5390
CRI
80
beam spread deg
120°
Electrical Specs
watt
30/40/50W
volts
120-277V
dimming type
0-10V Dimming
Compliance
location rating
Wet
warranty
5 Years
classification
DLC, ETL Listed
Downloads
IES
