G-12022
Glawre'

1x4 surface mount panel

1X4 Surface Mount Panel

30,35,41,50,65k
Dimmable
3660/4720/5750 Lumens
30/40/50 Watts
120-277 V
View full details

Information

General Specs
Product Code
G-12022
Description
GL/SM/1X4/50W/LED/WS3/5CCT
shape
1X4
finish
White
diffuser
Frosted
number of lights
1
OD (Outside dimensions)
11.92" X 47.71"
height
1.06"
mounting
Surface mount
Packaging Information
master pack
2
Barcode
024441120226
Light Specs
temp
Selectable CCT
Color (CCT)
30,35,41,50,65K
lumens
3660/4720/5750
CRI
80
beam spread deg
120°
Electrical Specs
watt
30/40/50W
volts
120-277V
output current
200-1000mA
dimming type
0-10V Dimming
Compliance
location rating
Wet
warranty
5 Years
classification
ETL, Title 24, Energy Star

Downloads

Product Spec Family Sheet Instruction Sheet

Accessories

Emergency LED Driver
G-48411 (30W) G-95521 (60W) G-95525 (25W)
