G-48429
Saturn

1.5" gimbal trimless (black)

1.5" Gimbal Trimless (Black)

27,30,35,41,50k
Dimmable
1000 Lumens
12 Watts
120-277 V
View full details

Information

General Specs
Product Code
G-48429
Description
R1.5/12W/GR/LED/TL/5CCT BK
shape
Round
style
Trimless
size
1.5 Inch
finish
Black
diffuser
Clear
number of lights
1
cutout
2.56”
OD (Outside dimensions)
3.54"
height
4.88"
mounting
Mud-in
Packaging Information
master pack
18
Barcode
696304484297
Light Specs
temp
Selectable CCT
Color (CCT)
27,30,35,41,50K
lumens
1000
CRI
>90
beam spread deg
40°
tilt angle
30°
rotating
360°
Electrical Specs
watt
12W
volts
120-277V
output current
270mA
dimming type
Triac Or 0-10V Dimming
Compliance
location rating
Wet
warranty
3 Years
IC Rated
Yes
classification
ETL, Title24 Listed

Downloads

Product Spec IES

Accessories

New construction plate
G-98800 (3 Punchouts) G-98810 (3 Punchouts) G-19982 (1 Punchouts)
Emergency LED Driver
G-48410 (15W) G-48411 (30W) G-95521 (60W) G-95525 (25W)
Extension Cords
G-20210 (6 Ft) G-20211 (10 Ft)
