G-96022
Aster

3 inch 9w interchangeable module

3 Inch 9W Interchangeable Module

Module:
27,30,35,41,50k
Dimmable
850 Lumens
9 Watts
120-277 V
View full details

Information

General Specs
Product Code
G-96022
Description
M3/9W/LED/5CCT
size
3 Inch
diffuser
Clear (Default)
mounting
Universal
Packaging Information
master pack
18
Barcode
024431960221
Light Specs
temp
Selectable CCT
Color (CCT)
27,30,35,41,50K
lumens
850
lumen effeciency
85
CRI
90>
beam spread deg
40° Clear (Default)
Electrical Specs
watt
9W
volts
120-277V
output current
210mA
plenum rated
FT6
dimming type
Triac Or 0-10V Dimming
Compliance
location rating
Wet
warranty
3 Years
IC Rated
Yes
classification
ETL, Title24 Listed

Downloads

Product Spec IES
